35-36 sedan delivery


Is the wood covered with tin covers or exposed on the rear door and B pillers of a sedan delivery?
Thanks

Re: 35-36 sedan delivery


It's covered with embossed cardboard. See enclosed specs from DeAngelis book and image from 1935 Dealer Truck Album

Re: 35-36 sedan delivery


Thank you Don. Unfortunately I found out 35-36 passenger car book doesn't cover the sedan delivery when searching through it, I assume the new commercial book will cover it. I see the inside surfaces use the cardboard material but what I am trying to find out is if there are tin plates to cover the wood in the door edge openings / surround of the rear door and B piller?

Re: 35-36 sedan delivery


https://www.fordbarn.com/forum/attac...5&d=1679963818

https://www.fordbarn.com/forum/attac...6&d=1679963818

Re: 35-36 sedan delivery


Yes. there are covers on the B pillar that cover the wood, It has been quite a few years since I've worked on ours BUT I believe they nail in place. I believe yes on the rear door opening too BUT I will have to go over to another storage garage and look for you to be 100% sure on the rear. As I think on it more, yes on the sides of the opening for sure BUT I don't think there was one on the top of the opening.......I think the sides stopped just before the curve of the opening???? Again, I will have to go and look for you to be 100% sure!!!

Re: 35-36 sedan delivery


Thank You rockfla. I thought there should be something covering it on the sides at least. The car is apart and scattered throughout a 5,000 foot warehouse. It's just like a treasure hunt.

Re: 35-36 sedan delivery


Ours is apart too, just not in a 5000sqr foot building, more like a 200 sqr foot garage. Might you have pictures of yours you could share of the inside structure around the rear wheel wells AND under the rear tail panel??? Here is a shot of a 34 I took at the 05 Western National......I know not 35 or 36 BUT you can see the rear opening detail around the latch part of the rear opening, also covered like on the 35/36. Unfortunately I cut the top off not knowing about "details"of which I was more interested in the floor detail!!! Maybe this helps too???

Re: 35-36 sedan delivery


Uncle buck
The ones for the "B" pillar should have the rectangle cut out for the latch mechanism for the doors to shut!!! SO they should be pretty easily identified. Here is our Delivery looking a lot nicer than it is now!!! ALSO "IF" you look at the picture of the rear opening you can see that there is one on the top of the opening as well as the sides!!!! They the B pillar ones and the side rears should also have a "rabbit" in the edges for the thickness of the door to fit in when shut as well IF I remember correctly?

Re: 35-36 sedan delivery


Re: 35-36 sedan delivery


Uncle Buck,
The 1935-1936 Model 51 book only covers the big trucks, not any of the commercial vehicles. I included a small amount of incidental information on the 1-1/2 ton panel trucks as I came across it. The book project was already so big I didn't have the energy or sources of good information to cover the entire panel truck body, the dump truck bodies or the service truck body, so most of the body information relates to the closed cab which doesn't help you.
Dave

Re: 35-36 sedan delivery


ouch ! They aren't giving that book away
https://www.ebay.com/itm/38223608434...3ABFBMsvH2puVh

Re: 35-36 sedan delivery


Re: 35-36 sedan delivery


Uncle Buck - We may be talking about different books. Your last post is a link to the Ford 1935 Truck Dealer Showroom Album. It covers basics for all truck and commercial vehicles Ford made in 1935. I was referring to the 1935-1936 Model 51 Truck book for sale by the Early Ford V8 Club:
https://shop.efv8.org/collections/fo...-shipping-rate
It just became available.

Re: 35-36 sedan delivery


https://cdn.shopify.com/s/files/1/24...g?v=1678721372


The 1935-1936 Ford Model 51 Truck Book, softbound - Regular price $60.00

Re: 35-36 sedan delivery


I'm sorry for the confusion. When you mentioned the new club book doesn't cover sedan delivery I thought I would search the "and image from 1935 Dealer Truck Album" that Don mentioned. That turned up a couple on the Bay for sale. The link I listed is for one of those.

Re: 35-36 sedan delivery


No worries. Don's the best source for information on the commercial panel trucks. If you can, visit the Early Ford V8 Museum in Auburn, IN where his 1936 Panel Delivery is on display. It's a wonderfully correct restoration.

Re: 35-36 sedan delivery


Here it is. Some assembly required. Also, can someone please post a picture of what the steel portion of the floor should look like?

Re: 35-36 sedan delivery


https://www.jalopyjournal.com/forum/...#post-13272024

This thread on the HAMB has good pics of the Jim McFall sedan delivery, including the rear jamb area.

Re: 35-36 sedan delivery


https://www.fordbarn.com/forum/attac...6&d=1680341446

https://www.fordbarn.com/forum/attac...7&d=1680341446

https://www.fordbarn.com/forum/attac...8&d=1680341446

https://www.fordbarn.com/forum/attac...9&d=1680341446

Re: 35-36 sedan delivery


Quote:

Originally Posted by uncle buck (Post 2215514) Also, can someone please post a picture of what the steel portion of the floor should look like?

See > https://www.jalopyjournal.com/forum/...ivery.1057605/
